FEATURE HIGHLIGHTS
? High Sensitivity
? Detection of both Magnetic and Non-Magnetic Metals
? Optical, Acoustical and
Vibration Alarm
? Long Battery Life
? Very High Reliability
? Easy to Use
? Self-Calibrating
? Fast Inductive Battery Charger
(optional for PD140VR model)
EnHAncEd HAnd HELd METAL dETEcToR
V140 Carrying Case
The special ergonomic shape of The
device allows inspecTion wiThouT The
inTerference of The operaTor’s fingers
SpEcIAL
ERGonoMIc
SHApEBc140F
PD140
8
Operating Features
Turning on the Metal Detector Operator Controls and Signali
Switch the 3-position Power/Mode switch from the central OFF
position to either left or right, depending on whether the device is
to be operated with audio/visual alarms (left) or with
audio/visual/vibration alarms (right).
The Metal Detector's ALARM LED will light up and the Alarm
Buzzer will be activated for a short time. During this operation,
keep the detection surface away from any metal objects until the
alarm signaling has gone out.
The POWER LED lights up to indicate that the device is operable.
Return the switch to the OFF position to turn off the device.
NOTE: the device emits brief audio/visual alarm whenever power is turned on,
end a brief visual alarm whenever power is turned off, or when power is lost.
OFF
ALARM LOW BATTERY POWER
Fig. 5
ALARM
LOW BAT
POWER
Power/Mo
? Lef
ala
? Rig
vib
Alarm Buz
Program Version: n/a Rev.: FI 005 GB100K2 v1 Date: 2005-10-21
MEdIUM
Low HIGH
1 2 3
4 5 6
EnHAncEd HAnd HELd METAL dETEcToR
ceia reserves the right to make changes, at any moment and without notice, to the models (including programming), their
accessories and optionals, to the prices and conditions of sale
Zona Industriale 54/G, 52041 Viciomaggio - Arezzo (ITALY)
Tel.: +39 0575 4181 Fax: +39 0575 418298 E-mail:
w w w . c e i a . n e t dp009 Uk 100k2V3-42090
TEcHnIcAL FEATURES
powER SUppLY
pd140V: 9V dry battery
or 9V niMH with contact charger
pd140VR: 9V niMH with BC140F inductive charger
THREE-poSITIon SwITcH wITH SELEcTIon
oF Two dIFFEREnT ALARM ModES
simultaneous optical and acoustic alarm.
Built-in buzzer (75 dBa at a distance of 90 cm)
Optical alarm and handle vibration
SEnSITIVITY AdjUSTMEnT BY MEAnS oF A THREE-poSITIon ExTERnAL SELEcToR
BATTERY LIFE In conTInUoUS opERATIon
with alkaline batteries: 150 hours max
with niMH batteries: 40 hours max
IndIcAToR LAMpS FoR
Power on (green light)
alarm (red light)
Low battery charge (blinking yellow light)
opERATInG TEMpERATURE -15°C to 65°C (relative humidity: 0 to 95% )
Manufactured in grey, shock-resistant Polycarbonate and aBs blend
dIMEnSIonS 340 x 80 x 55 mm
wEIGHT (wITH BATTERY) 0.400 kg
Conforms to the international standards currently applicable for electrical safety, e.M.C. and to the applicable
Ce regulations
opERAToR conTRoLS
And SIGnALLInG dEVIcES
1 ALARM Red Light: alarm signalling
2 Low BATTERY Yellow light:
Low Battery signalling
(blinking)
3 powER Green light: “Power on”
and “ready” status signalling.
When charging on the BC140F,
indicates the status of the charge
4 SEnSITIVITY AdjUSTMEnT
5 powER/ModE switch
? Left position: visual and audible alarm
signalling
? Right position: visual and vibration
alarm signalling
6 ALARM BUZZER
Bc140F
FAST IndUcTIVE BATTERY cHARGER
V140
cARRYInG cASE
The Bc140F unit provides recharging, without
electrical contact, of the niMH batteries in the
pd140VR Metal detectors. The BC140F battery
charger is designed to be able to be connected
in cascade with other similar devices.
TEcHnIcAL FEATURES
powER SUppLY: 90-265Vrms, 50/60 Hz, 4 W
REcHARGInG TIME: 4 hours or less (complete cycle)
on/oFF switch with indicator lamp
Connection in cascade with other similar devices
(up to 20 units)
dIMEnSIonS: 82 x 155 x 97 (h) mm
wEIGHT: 0.500 kg
LEnGTH oF MAInS cABLE: 1.80 m
Length of cable for connecting units in cascade: 0.17 m
Manufactured in grey, shock-resistant aBs
Conforms to the international standards currently
applicable for electrical safety, e.M.C. and to the
applicable Ce regulations
The V140 carrying-case, in shock-resistant
material, is designed to contain the following
items: a PD140 Hand Held Metal Detector, a
test piece, a BC140F fast battery-charger, a
power supply cable and the instructions for
use.
TEcHnIcAL FEATURES
dIMEnSIonS: 445 x 300 x 180 mm
wEIGHT: 2.300 kg including PD140 and battery
charger
shock-resistant aBs construction and the special
storage compartments make the V140 carryingcase the ideal, safest and most compact means of
transporting the PD140
Conforms to the international standards currently
applicable for electrical safety, e.M.C. and to the
applicable Ce regulations
GREEn LEd
blinking: charge in progress;
steady after blinking: charge
completed
powER LAMp
on/oFF SwITcH
The PD140 enhanced Hand Held Metal Detector is a high sensitivity device designed
to detect magnetic and non-magnetic metal masses.
The unit can be used to detect weapons, detonators and other small pieces of metal
concealed in baggage or correspondence.
The bidirectional detection probe allows both sides to detect metals evenly. The
sensitivity of the surface is enhanced by the shape making operation of the device
reliable and easy to operate.
The PD140 Metal Detector is available in two standard sensitivity versions: pd140V
and pd140VR (model equipped for no-contact induction battery charger). Both are
available with a 9V dry battery or rechargeable ni/MH batteries.
